2024 Knolly
Fugitive 140 XT
A 29″ aluminum frame full suspension trail bike with high-end components.
Compare the full range
Manufacturer Price
$5,799| Frame | Aluminum |
|---|---|
| Suspension | Full, 140 / 150mm |
| Fork | Fox Factory Float 36 |
| Shock | Fox Float X Factory |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | XT |
| Brakes | Hydraulic Disc |
| Seatpost | Dropper |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Fugitive model range
View Comparison
Apr 2024
The most popular 29er Knolly trail bike debuts with a completely new tubeset, straight top tube design, and refreshed geo.
Apr 2024 · Knolly Bikes
The new Fugitive receives updated geometry and undergoes the straight top tube treatment.
Aug 2021 · Jason_Schroeder
The established climbing machine elevates its well-rounded abilities with key updates that improve descending abilities.
Increased reach and wheelbase improves composure and stability descending
FOX suspension provides bottomless ride for aggressive riding
Incredibly planted and efficient pedaling platform
Low bottom bracket leads to many pedal strikes
29x2.3 Maxxis tires are too narrow for rowdy descents
Lacks playful, trail bike demeanor
Jun 2021 · Travis Engel
The Knolly Fugitive combines eager pedaling with a ruthless appetite for speed. It’s never too much, or too little bike for the occasion.
Efficient, rewarding pedaler
Highly capable for its travel and geometry
Unique combination of stability and maneuverability
Not cheap for an aluminum bike
Not as supple as other bikes around 140mm of travel
Apr 2021
Knolly Bikes revises their Fugitive for 2021, updating the frame geometry and adding a few extra millimeters of rear travel.
| Frame | 6066 Aluminum, Custom Titanium Hardware BB Standard: BSA, 73mm, Threaded Colors: Raw; Anodized Bronze; Dad Jean Blue; Chameleon Purple |
|---|---|
| Fork | Fox 36 29" Grip2 Factory 150mm, 44mm offset Travel: 150mm Spring Type: Air |
| Shock | Fox Float X Factory 185x55 Travel: 140mm Spring Type: Air |
| Bottom Bracket | Shimano XT MT800 BSA, threaded |
| Headset | Cane Creek 40 ZS44/56 |
| Stem | RaceFace Aeffect R 35mm x 50mm |
| Handlebar | Spank 35mm x 800mm, 25mm Rise |
| Saddle | SDG Bel-Air V3 |
| Seatpost | SDG Tellis (S: 170mm, M-XL 200mm), 31.6 Type: Dropper |
| Grips | Spank Spoon |
| Rear Derailleur | Shimano XT M8100 12spd, Shadow Plus |
|---|---|
| Crank | Shimano XT M8130 30T, 170mm |
| Shifters | Shimano XT 12spd M8100 (I-Spec EV) |
| Cassette | Shimano XT M8100 12spd, 10-51T, Hyperglide+ |
| Chain | Shimano XT M8100 |
| Brakes | Shimano XT 4 Piston M8120 Type: Hydraulic Disc |
| Rims | Spank 359 HEX J-Bend 32h (MS) |
|---|---|
| Tires | Front: Maxxis Assegai 29" 2.5WT 3C MaxxGrip EXO+, Rear: Maxxis DHR2 29" 2.4" 3C MaxxTerra EXO+ |
| Disc Rotors | Shimano XT 203mm / 180mm (6-Bolt) SM-RT76 |
Last updated May 11
